Choosing the 2 Pairs (4 Core) Unshielded Instrumentation Cable

Two pairs serve one or two 4–20 mA loops, the typical run from a single transmitter to its junction box. No metallic screen keeps it light, flexible and quick to terminate; choose it for clean electrical environments where the route stays away from mains power and motor drives.

Order code: P02U-MC. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT 2 Pairs (4 Core) Unshielded Instrumentation Cable Series

TMT Global 2 Pairs (4 Core) Unshielded Instrumentation Cable is a configurable instrumentation-cable family for analogue, digital and process-control signals between field instruments, control panels, PLC/DCS systems and monitoring equipment. The product page fixes the 2 pairs (4 core) unshielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.

KEY FEATURES

2 Pairs (4 Core) controlled twisted-pair construction
No metallic screen; use only where EMC and crosstalk conditions permit
14, 16, 18, 20, 22 and 24 AWG Series options
PVC, LSZH and outdoor PE jacket choices
Bare-copper conductor; solid or stranded by released drawing
Exact searchable ordering code for every standard combination

TYPICAL APPLICATIONS

4–20 mA and 0–10 V instrumentation loops
Process measurement, transmitters and monitoring circuits
PLC/DCS analogue and digital I/O wiring
RTD, valve, actuator and positioner circuits
Industrial plants, utilities and building-services systems

Technical Specification

PARAMETER	SPECIFICATION
Product type	Instrumentation and process-control cable
Element configuration	2 pairs / 4 insulated cores
Conductor material	Bare copper
Conductor construction	Solid or stranded construction
Available conductor sizes	14 / 16 / 18 / 20 / 22 / 24 AWG
Element formation	Two insulated conductors twisted as each pair
Core insulation	PVC / PE / halogen-free compound options, construction dependent
Screening	No metallic screen; use only where EMC and crosstalk conditions permit
Outer-jacket options	PVC / LSZH / PE Outdoor
Cable form	Round
Standard colours	Grey for PVC/LSZH; black for PE Outdoor
Package length	305 m standard TMT package
Ordering basis	AWG and jacket define the exact searchable Series SKU
Series records	18 searchable Series SKUs per family

AWG / NOMINAL AREA MATRIX

AWG	NOMINAL AREA	SERIES AVAILABILITY
14 AWG	2.08 mm²	PVC / LSZH / PE Outdoor • 305 m • Project option
16 AWG	1.31 mm²	PVC / LSZH / PE Outdoor • 305 m • Standard / project
18 AWG	0.823 mm²	PVC / LSZH / PE Outdoor • 305 m • Main market
20 AWG	0.518 mm²	PVC / LSZH / PE Outdoor • 305 m • Main market
22 AWG	0.326 mm²	PVC / LSZH / PE Outdoor • 305 m • Main market
24 AWG	0.205 mm²	PVC / LSZH / PE Outdoor • 305 m • Standard / project

Additional information

Brand	TMT Global
AWG	14 awg, 16 awg, 18 awg, 20 awg, 22 awg, 24 awg
Colour	Black, Grey
Jacket Type	PVC, LSZH, PE Outdoor
Length	305 m

Download

For Products Specification /PDF

HTTPS://TMTGLOBAL.CO.UK

Ordering Information

Item Name	Series	AWG / mm²	Jacket	Colour	Pack
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	14 awg	PVC	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	14 awg	LSZH	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	14 awg	PE Outdoor	Black	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	16 awg	PVC	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	16 awg	LSZH	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	16 awg	PE Outdoor	Black	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	18 awg	PVC	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	18 awg	LSZH	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	18 awg	PE Outdoor	Black	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	20 awg	PVC	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	20 awg	LSZH	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	20 awg	PE Outdoor	Black	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	22 awg	PVC	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	22 awg	LSZH	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	22 awg	PE Outdoor	Black	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	24 awg	PVC	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	24 awg	LSZH	Grey	305 m
2 Pairs (4 Core) Unshielded Instrumentation Cable	P02U-MC	24 awg	PE Outdoor	Black	305 m
