20 Core Foil + Braid Shielded PLC I/O Cable

Choosing the 20 Core Foil + Braid Shielded PLC I/O Cable

20 cores match a typical PLC I/O module, so one cable can connect a full card to a terminal or marshalling panel. Foil plus tinned-copper braid gives the strongest protection against electrical noise and adds mechanical strength, which is why it is the usual choice in plant rooms, near VFDs and motors, and across industrial sites.

Related options in this range: 12 Core Foil + Braid Shielded PLC I/O Cable · 16 Core Foil + Braid Shielded PLC I/O Cable · 20 Core Foil Shielded PLC I/O Cable · 20 Core Unshielded PLC I/O Cable

Order code: 20B-PL. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 20 Core Foil + Braid Shielded PLC I/O Cable Series

TMT Global 20 Core Foil + Braid Shielded PLC I/O Cable is a configurable multicore cable family for digital and analogue PLC/DCS I/O signals between controller cabinets, remote-I/O stations, marshalling panels and field devices. The product page fixes the 20-core foil + braid shielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.

KEY FEATURES

• 20-core controlled construction
• Overall foil + tinned-copper braid + drain wire
• 16, 18, 20, 22 and 24 AWG Series options
• PVC, LSZH and outdoor PE jacket choices
• Bare-copper conductor; solid or stranded by released drawing
• Exact searchable ordering code for every standard combination

TYPICAL APPLICATIONS

• PLC and DCS digital / analogue I/O circuits
• Remote-I/O racks, marshalling panels and controller cabinets
• Sensors, encoders, solenoids, valves and actuators
• OEM machine interfaces and industrial automation interconnection
• Protocol-specific network cables are listed separately under Bus Cables

Technical Specification

AWG / NOMINAL AREA / SERIES AVAILABILITY
