TMT Global 14-Core Separable Peel OSDP Access Control Composite, black composite access-control cable with peelable/separable parallel subcables, foil-shielded OSDP data pair and separated reader/lock power groups, exactly fourteen insulated copper conductor tips.

14 Core Separable Peel OSDP Access Control Composite

KEY FEATURES

  • Access-control-specific construction
  • 1PR22 + 2C18 + 6C22 + 4C18
  • OSDP pair shielded
  • 305 m standard package
  • Factory evidence required for released electrical values
Chat with Sales
View / Print DatasheetContact Sales
0 People watching this product now!
Description

TMT 14 Core Separable Peel OSDP Access Control Composite Series

TMT Global 14 Core Separable Peel OSDP Access Control Composite is a controlled Security & ELV cable family for professional door access-control installations. Separable OSDP access-control composite for a single-pull installation while retaining a true shielded RS-485 reader pair and dedicated power/auxiliary legs. Jacket and permitted conductor-size variations remain exact searchable Series rows under this product page.

KEY FEATURES

  • Access-control-specific construction
  • 1PR22 + 2C18 + 6C22 + 4C18
  • OSDP pair shielded
  • 305 m standard package
  • Factory evidence required for released electrical values

APPLICATIONS

  • OSDP door installations
  • Single-pull access cabling
  • Field-separated door circuits

Technical Specifications

PARAMETER TECHNICAL SPECIFICATION
Product family 14 Core Separable Peel OSDP Access Control Composite
Series OSDP-PEEL-AXBP
Primary function Separable OSDP composite
Conductor schedule 1PR22 + 2C18 + 6C22 + 4C18
Conductor construction Stranded copper conductors
Screening OSDP pair shielded
Cable form Separable peel / application-coloured subcables
Jacket options PVC / LSZH
Standard colours Grey
Standard package 305 m
Installation / protocol OSDP / 2-wire RS-485 access-control link
Series status PVC / LSZH: Core market

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA (mm²) SERIES AVAILABILITY
18 AWG 0.823 PVC / LSZH
22 AWG 0.326 PVC / LSZH
Additional information
AWG22 awg
BrandTMT Global
ColourGrey
Jacket TypePVC, LSZH
Length305 m
Download

For Products Specification /PDF

HTTPS://TMTGLOBAL.CO.UK

Ordering Information
Item NameItem Code / SKUSeriesAWG / mm²JacketColourPackQR Code
14 Core Separable Peel OSDP Access Control CompositeOSDP-PEEL-AXBP22 awgPVCGrey305 m QR code for 1422BPSEG-AXBP
14 Core Separable Peel OSDP Access Control CompositeOSDP-PEEL-AXBP22 awgLSZHGrey305 m QR code for 1422BLSEG-AXBP
