TMT Global 16-Core Heavy-Duty Access Control Composite Cable, heavy-duty black outer jacket, foil-screened data pair plus separate power and control cores, exactly sixteen distinct insulated copper conductors, sixteen clean visible wire tips.

16 Core Heavy-Duty Access Control Composite

KEY FEATURES

  • Access-control-specific construction
  • 3PR18 + 2C18 + 4C18 + 4C16
  • Reader pair(s) shielded
  • 305 m standard package
  • Factory evidence required for released electrical values
Chat with Sales
View / Print DatasheetContact Sales
0 People watching this product now!
Description

TMT 16 Core Heavy-Duty Access Control Composite Series

TMT Global 16 Core Heavy-Duty Access Control Composite is a controlled Security & ELV cable family for professional door access-control installations. Heavy-gauge access-control composite for projects requiring lower voltage drop or higher current capacity in reader, auxiliary and locking circuits. The mixed-gauge composition is fixed by the Series definition. Jacket and permitted conductor-size variations remain exact searchable Series rows under this product page.

KEY FEATURES

  • Access-control-specific construction
  • 3PR18 + 2C18 + 4C18 + 4C16
  • Reader pair(s) shielded
  • 305 m standard package
  • Factory evidence required for released electrical values

APPLICATIONS

  • Higher-load locks
  • Longer door circuits
  • Industrial access points

Technical Specifications

PARAMETER TECHNICAL SPECIFICATION
Product family 16 Core Heavy-Duty Access Control Composite
Series ACC-HD-ACHD
Primary function Heavy-duty composite
Conductor schedule 3PR18 + 2C18 + 4C18 + 4C16
Conductor construction Stranded copper conductors
Screening Reader pair(s) shielded
Cable form Round / common jacket
Jacket options PVC / LSZH / PE Outdoor
Standard colours Grey / Black
Standard package 305 m
Installation / protocol Low-voltage access-control wiring
Series status PVC / LSZH: Core market; PE Outdoor: Outdoor / project

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA (mm²) SERIES AVAILABILITY
16 AWG 1.31 PVC / LSZH / PE Outdoor
18 AWG 0.823 PVC / LSZH / PE Outdoor
Additional information
AWG18 awg
BrandTMT Global
ColourBlack, Grey
Jacket TypePVC, LSZH, PE Outdoor
Length305 m
Download

For Products Specification /PDF

HTTPS://TMTGLOBAL.CO.UK

Ordering Information
Item NameItem Code / SKUSeriesAWG / mm²JacketColourPackQR Code
16 Core Heavy-Duty Access Control CompositeACC-HD-ACHD18 awgPVCGrey305 m QR code for 1618BPSRG-ACHD
16 Core Heavy-Duty Access Control CompositeACC-HD-ACHD18 awgLSZHGrey305 m QR code for 1618BLSRG-ACHD
16 Core Heavy-Duty Access Control CompositeACC-HD-ACHD18 awgPE OutdoorBlack305 m QR code for 1618BKSRK-ACHD
