TMT Global 2-Core Door Lock / Electric Strike Power Cable, robust black outer jacket, exactly two heavier red and black insulated stranded copper power conductors, two clear tips, no additional cores.

2 Core Door Lock / Electric Strike Power Cable

KEY FEATURES

  • Access-control-specific construction
  • 2C 16/18 AWG
  • Unshielded
  • 305 m standard package
  • Factory evidence required for released electrical values
Chat with Sales
View / Print DatasheetContact Sales
0 People watching this product now!
Description

Choosing the 2 Core Door Lock / Electric Strike Power Cable

Two cores suit one device: a lock, exit button, door contact or a powered sensor.

Related options in this range: 2-Wire Bus + 2 Core Power Composite Intercom Cable · OSDP Long-Run Reader Cable – 1 Pair 22 AWG + 2 Core 16 AWG Power · OSDP Reader Cable – 1 Pair 22 AWG + 2 Core 18 AWG Power · 2 Core Door Contact Cable · 2 Core Door Lock / Electric Strike Power Cable

Order code: 02U-AK. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT 2 Core Door Lock / Electric Strike Power Cable Series

TMT Global 2 Core Door Lock / Electric Strike Power Cable is a controlled Security & ELV cable family for professional door access-control installations. Dedicated low-voltage power cable for electric strikes, magnetic locks and similar access-control locking devices. The two-core construction is kept separate from general security-control multi-core products because its primary function is lock power delivery. Jacket and permitted conductor-size variations remain exact searchable Series rows under this product page.

KEY FEATURES

  • Access-control-specific construction
  • 2C 16/18 AWG
  • Unshielded
  • 305 m standard package
  • Factory evidence required for released electrical values

APPLICATIONS

  • Electric strikes
  • Magnetic locks
  • Door locking hardware

Technical Specifications

PARAMETER TECHNICAL SPECIFICATION
Product family 2 Core Door Lock / Electric Strike Power Cable
Series 02U-AK
Primary function Lock / strike power
Conductor schedule 2C 16/18 AWG
Conductor construction Stranded copper conductors
Screening Unshielded
Cable form Round / common jacket
Jacket options PVC / LSZH / PE Outdoor
Standard colours Grey / Black
Standard package 305 m
Installation / protocol Low-voltage access-control power wiring
Series status PVC / LSZH: Core market; PE Outdoor: Outdoor / project

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA (mm²) SERIES AVAILABILITY
16 AWG 1.31 PVC / LSZH / PE Outdoor
18 AWG 0.823 PVC / LSZH / PE Outdoor
Additional information
AWG16 awg, 18 awg
ColourBlack, Grey
Jacket TypePVC, LSZH, PE Outdoor
BrandTMT Global
Download

For Products Specification /PDF

HTTPS://TMTGLOBAL.CO.UK

Ordering Information
Item NameItem Code / SKUSeriesAWG / mm²JacketColourQR Code
2 Core Door Lock / Electric Strike Power Cable02U-AK16 awgPVCGrey QR code for 0216BPURG-AK
2 Core Door Lock / Electric Strike Power Cable02U-AK16 awgLSZHGrey QR code for 0216BLURG-AK
2 Core Door Lock / Electric Strike Power Cable02U-AK16 awgPE OutdoorBlack QR code for 0216BKURK-AK
2 Core Door Lock / Electric Strike Power Cable02U-AK18 awgPVCGrey QR code for 0218BPURG-AK
2 Core Door Lock / Electric Strike Power Cable02U-AK18 awgLSZHGrey QR code for 0218BLURG-AK
2 Core Door Lock / Electric Strike Power Cable02U-AK18 awgPE OutdoorBlack QR code for 0218BKURK-AK
