Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable
KEY FEATURES
- 1 × 2 × 0.8 mm solid bare-copper twisted-pair construction
- Overall foil + tinned-copper braid + drain wire
- PVC green, LSZH green and PE Outdoor black ordering options
- 20 AWG item-code field representing the 0.8 mm KNX conductor format
- Exact searchable made-to-order SKU for every declared jacket option
- 305 m standard TMT package; project lengths subject to release
Chat with Sales
0
People watching this product now!
Description
Choosing the Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable
Two cores connect a single smart-home device such as a keypad, sensor or bus line. Foil plus tinned-copper braid gives the strongest protection against electrical noise and adds mechanical strength, which is why it is the usual choice in plant rooms, near VFDs and motors, and across industrial sites.
Related options in this range: Custom 2 Pair (4 Core) Foil + Braid Shielded KNX TP Bus Cable · 1 Pair (2 Core) Foil Shielded KNX TP Bus Cable · 1 Pair 2 core KNX Control Cable LSHF 305m Roll
Order code: 02B-KX SERIES. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT Global Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable Series
TMT Global Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable is a controlled twisted-pair cable family for KNX TP building-automation bus installations. This is a TMT custom / special-project construction and is not presented as the mainstream KNX TP standard. The product page fixes the 1 × 2 × 0.8 mm foil + braid shielded construction, while the TMT Series ordering table provides exact jacket-specific item codes for customer search, quotation and project selection.
KEY FEATURES
- 1 × 2 × 0.8 mm solid bare-copper twisted-pair construction
- Overall foil + tinned-copper braid + drain wire
- PVC green, LSZH green and PE Outdoor black ordering options
- 20 AWG item-code field representing the 0.8 mm KNX conductor format
- Exact searchable made-to-order SKU for every declared jacket option
- 305 m standard TMT package; project lengths subject to release
TYPICAL APPLICATIONS
- KNX TP bus lines and device interconnection
- Lighting, HVAC, blinds and room-control networks
- Residential, commercial, hospitality and public buildings
- Compact single-pair KNX TP installation
- Industrial / higher-EMI special projects subject to factory and KNX evaluation
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | KNX TP bus cable family |
| Pair / core configuration | 1 × 2 × 0.8 mm (1 pair / 2 core) |
| Conductor | Solid bare copper, nominal 0.8 mm diameter |
| Nominal conductor area | 0.50 mm² nominal (derived from 0.8 mm diameter) |
| Core insulation | Polyethylene or equivalent insulation for the declared KNX TP construction |
| Screening | Overall foil + tinned-copper braid + drain wire |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Standard colours | Green for PVC/LSZH; black for PE Outdoor |
| Cable form | Round |
| Installation | Fixed KNX TP bus installation |
| Package length | 305 m standard TMT package |
| Item-code designation | 20 AWG code represents the nominal 0.8 mm solid-conductor KNX format |
| Series position | Made-to-order / special-project family |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG / NOMINAL AREA | SERIES AVAILABILITY |
| 20 AWG / 0.50 mm² | PVC Green • 305 m |
| 20 AWG / 0.50 mm² | LSZH Green • 305 m |
| 20 AWG / 0.50 mm² | PE Outdoor Black • 305 m |
| 20 AWG / 0.50 mm² | 02B-KX SERIES • 3 searchable SKUs |
Additional information
| AWG | 20 awg |
|---|---|
| Brand | TMT Global |
| Colour | Black, Green |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
Download
Ordering Information
| Item Name | Item Code / SKU | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|
| Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable | 20 awg | PVC | Green | 305 m |  | |
| Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable | 20 awg | LSZH | Green | 305 m | | |
| Custom 1 Pair (2 Core) Foil + Braid Shielded KNX TP Bus Cable | 20 awg | PE Outdoor | Black | 305 m | |
