2 Core Foil-Shielded PA / Intercom Cable

KEY FEATURES

  • Two stranded bare-copper conductors
  • Overall aluminium/polyester foil screen and drain wire
  • PVC, LSZH and PE Outdoor jacket options
  • Exact searchable Series item codes
  • 305 m controlled standard package
Chat with Sales

Supplied in the UAE by AMSS from our Sharjah office (Industrial Area 18) and Dubai office (Naif, Deira), for projects across the Emirates. Request a quote

0 People watching this product now!
Description

Choosing the 2 Core Foil-Shielded PA / Intercom Cable

Choose PA system cable by conductor size for the run length and line load, then by jacket for the building and route. Jacket options: PVC for general indoor routes, LSZH where low smoke and zero halogen are specified for occupied buildings, PE for outdoor routes.

  • Type: PA / paging / intercom bulk cable
  • Cores / pairs: 2 core
  • Conductor size: 14 AWG / 16 AWG / 18 AWG / 20 AWG / 22 AWG
  • Conductor: Stranded copper conductors
  • Screen: Overall foil screen
  • Drain wire: Drain wire included
  • Package: 305 m standard package

Related options in this range: 3 Core Foil-Shielded PA / Paging Cable · 4 Core Foil-Shielded PA / Control Cable · 2 Pair Foil-Shielded PA / Intercom Cable · 4 Pair Foil-Shielded PA / Intercom Cable

Order code: 02C-S-PA. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 2 Core Foil-Shielded PA / Intercom Cable Series

TMT Global 2 Core Foil-Shielded PA / Intercom Cable is a configurable bulk-cable family for public-address audio, intercom, paging and low-voltage control circuits where overall foil screening is required. The family page carries exact AWG and jacket item codes without creating duplicate WooCommerce pages.

KEY FEATURES

  • Two stranded bare-copper conductors
  • Overall aluminium/polyester foil screen and drain wire
  • PVC, LSZH and PE Outdoor jacket options
  • Exact searchable Series item codes
  • 305 m controlled standard package

TYPICAL APPLICATIONS

  • Public-address audio circuits
  • Intercom and paging systems
  • Sound-system control wiring
  • Commercial building audio interfaces
  • Indoor and outdoor system routes

Technical Specification

AWG / NOMINAL AREA / SERIES AVAILABILITY

Additional information
BrandTMT Global
Jacket TypePVC, LSZH, PE Outdoor
AWG14 awg, 16 awg, 18 awg, 20 awg, 22 awg
ColourBlack, Grey
Length305 m
