4 Pair Foil-Shielded PA / Intercom Cable

KEY FEATURES

  • Four twisted pairs / eight conductors
  • Overall foil screen and drain wire
  • Multi-channel PA and intercom capability
  • PVC, LSZH and PE Outdoor jackets
  • Exact item-code rows under one family page
Chat with Sales

Supplied in the UAE by AMSS from our Sharjah office (Industrial Area 18) and Dubai office (Naif, Deira), for projects across the Emirates. Request a quote

0 People watching this product now!
Description

Choosing the 4 Pair Foil-Shielded PA / Intercom Cable

Choose PA system cable by conductor size for the run length and line load, then by jacket for the building and route. Jacket options: PVC for general indoor routes, LSZH where low smoke and zero halogen are specified for occupied buildings, PE for outdoor routes.

  • Type: Screened PA / intercom multi-pair cable
  • Cores / pairs: 4 twisted pairs / 8 cores
  • Conductor size: 18 AWG / 20 AWG / 22 AWG / 24 AWG
  • Conductor: Stranded copper conductors
  • Screen: Overall foil screen
  • Drain wire: Drain wire included
  • Package: 305 m standard package

Related options in this range: 2 Core Standard Fire-Resistant Voice Alarm Cable · 2 Pair Foil-Shielded PA / Intercom Cable · 3 Core Standard Fire-Resistant Voice Alarm Cable · 4 Core Standard Fire-Resistant Voice Alarm Cable

Order code: 04P-S-PI. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 4 Pair Foil-Shielded PA / Intercom Cable Series

TMT Global 4 Pair Foil-Shielded PA / Intercom Cable provides four twisted pairs within one screened jacket for multi-channel paging, intercom and commercial-audio control applications. Pair geometry is maintained as a separate physical family from generic eight-core cable

KEY FEATURES

  • Four twisted pairs / eight conductors
  • Overall foil screen and drain wire
  • Multi-channel PA and intercom capability
  • PVC, LSZH and PE Outdoor jackets
  • Exact item-code rows under one family page

TYPICAL APPLICATIONS

  • PA and intercom backbone wiring
  • Multiple paging channels
  • Call-station and zone-control links
  • Commercial-audio rack interconnection
  • Multi-circuit building communication

Technical Specification

AWG / NOMINAL AREA / SERIES AVAILABILITY

Additional information
BrandTMT Global
AWG18 awg, 20 awg, 22 awg, 24 awg
ColourBlack, Grey
Jacket TypePVC, LSZH, PE Outdoor
Length305 m
