2 Core Foil + Braid Double-Shielded Flexible Microphone Cable
KEY FEATURES
- Balanced two-core microphone geometry
- Foil plus overall copper braid for enhanced screening
- 20, 22 and 24 AWG Series options
- PVC, LSZH and PUR / TPU jacket options
- Factory-controlled capacitance, shield coverage and flexibility
Full specifications & datasheet: tmtglobal.co.uk →
Supplied in the UAE by AMSS from our Sharjah office (Industrial Area 18) and Dubai office (Naif, Deira), for projects across the Emirates. Request a quote
Choosing the 2 Core Foil + Braid Double-Shielded Flexible Microphone Cable
Microphone cable carries low-level balanced audio, so screening and flexibility matter most. Choose the pair count for the channels on the run and the jacket for fixed or stage use. Jacket options: PVC for general indoor routes, LSZH where low smoke and zero halogen are specified for occupied buildings.
- Type: Professional balanced microphone and low-level analogue audio cable
- Cores / pairs: 1 balanced pair / 2 core
- Conductor size: 20 AWG / 22 AWG / 24 AWG
- Conductor: Stranded copper
- Screen: Foil screen + drain wire + copper braid
- Package: 305 m
Related options in this range: 4 Core Star-Quad Copper-Braid Shielded Microphone Cable · 2 Core Copper-Braid Shielded Flexible Microphone Cable · 4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable · 2 Core Miniature Copper-Braid Shielded Microphone Cable
Order code: 02B-MI. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT Global 2 Core Foil + Braid Double-Shielded Flexible Microphone Cable Series
TMT Global 2 Core Foil + Braid Double-Shielded Flexible Microphone Cable combines a balanced two-core signal pair with foil screening, drain wire and an overall copper braid for demanding professional-audio environments. AWG and jacket variants are listed in the ordering table with their exact order codes.
KEY FEATURES
- Balanced two-core microphone geometry
- Foil plus overall copper braid for enhanced screening
- 20, 22 and 24 AWG Series options
- PVC, LSZH and PUR / TPU jacket options
- Factory-controlled capacitance, shield coverage and flexibility
TYPICAL APPLICATIONS
- High-EMI stages and equipment rooms
- Broadcast, studio and live production
- Longer microphone runs and installed AV
- Touring audio and portable stage systems
- Premium XLR microphone assemblies
Technical Specification
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | 20 awg, 22 awg, 24 awg |
|---|---|
| Brand | TMT Global |
| Jacket Type | PUR / TPU, PVC, LSZH |
| Length | 305 m |
| Colour | Black |
