2 Pair / 4 Core Foil + Braid Shielded Stereo Microphone Cable

KEY FEATURES

  • Two balanced pairs / four insulated conductors
  • Foil plus overall copper braid
  • 20, 22 and 24 AWG Series options
  • PVC, LSZH and PUR / TPU jacket options
  • Exact SKU row for each conductor and jacket combination
Chat with Sales

Supplied in the UAE by AMSS from our Sharjah office (Industrial Area 18) and Dubai office (Naif, Deira), for projects across the Emirates. Request a quote

0 People watching this product now!
Description

Choosing the 2 Pair / 4 Core Foil + Braid Shielded Stereo Microphone Cable

Microphone cable carries low-level balanced audio, so screening and flexibility matter most. Choose the pair count for the channels on the run and the jacket for fixed or stage use. Jacket options: PVC for general indoor routes, LSZH where low smoke and zero halogen are specified for occupied buildings.

  • Type: Stereo / dual-channel balanced microphone and analogue audio cable
  • Cores / pairs: 2 balanced pairs / 4 core
  • Conductor size: 20 AWG / 22 AWG / 24 AWG
  • Conductor: Stranded copper
  • Screen: Foil screen + drain wire + copper braid
  • Package: 305 m

Related options in this range: 2 Pair / 4 Core Foil-Shielded Stereo Microphone Cable · 2 Core Foil-Shielded Installation Microphone Cable · 2 Core Miniature Copper-Braid Shielded Microphone Cable · 4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable

Order code: 04B-MS. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 2 Pair / 4 Core Foil + Braid Shielded Stereo Microphone Cable Series

TMT Global 2 Pair / 4 Core Foil + Braid Shielded Stereo Microphone Cable combines two balanced channels with foil, drain wire and an overall copper braid. It is positioned for stereo microphone systems and dual-channel low-level audio in demanding environments where enhanced screen architecture is required.

KEY FEATURES

  • Two balanced pairs / four insulated conductors
  • Foil plus overall copper braid
  • 20, 22 and 24 AWG Series options
  • PVC, LSZH and PUR / TPU jacket options
  • Exact SKU row for each conductor and jacket combination

TYPICAL APPLICATIONS

  • Stereo microphone and dual-channel audio systems
  • Broadcast, studio and live production
  • High-EMI technical and stage environments
  • Premium dual-channel XLR assemblies
  • Conference and special microphone arrays

Technical Specification

AWG / NOMINAL AREA / SERIES AVAILABILITY

Additional information
BrandTMT Global
Jacket TypePUR / TPU, PVC, LSZH
Length305 m
ColourBlack
AWG20 awg, 22 awg, 24 awg
