2 Core Foil-Shielded Installation Microphone Cable

KEY FEATURES

  • Fixed-installation balanced pair geometry
  • Overall aluminium/polyester foil screen with drain wire
  • 18, 20 and 22 AWG Series options
  • PVC, LSZH and PE Outdoor jacket options
  • 305 m standard bulk-cable package
Chat with Sales

Supplied in the UAE by AMSS from our Sharjah office (Industrial Area 18) and Dubai office (Naif, Deira), for projects across the Emirates. Request a quote

0 People watching this product now!
Description

Choosing the 2 Core Foil-Shielded Installation Microphone Cable

Microphone cable carries low-level balanced audio, so screening and flexibility matter most. Choose the pair count for the channels on the run and the jacket for fixed or stage use. Jacket options: PVC for general indoor routes, LSZH where low smoke and zero halogen are specified for occupied buildings, PE for outdoor routes.

  • Type: Fixed-installation balanced microphone and low-level analogue audio cable
  • Cores / pairs: 1 balanced pair / 2 core
  • Conductor size: 18 AWG / 20 AWG / 22 AWG
  • Conductor: Stranded copper
  • Screen: Overall aluminium/polyester foil screen + drain wire
  • Package: 305 m

Related options in this range: 2 Core Miniature Copper-Braid Shielded Microphone Cable · 2 Pair / 4 Core Foil-Shielded Stereo Microphone Cable · 4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable · 2 Pair / 4 Core Foil + Braid Shielded Stereo Microphone Cable

Order code: 02S-MI. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 2 Core Foil-Shielded Installation Microphone Cable Series

TMT Global 2 Core Foil-Shielded Installation Microphone Cable is designed as a fixed-installation balanced microphone and low-level audio family for conduits, trays, wall plates, floor boxes, racks and central equipment rooms. The foil screen and drain wire support efficient termination, while AWG and jacket remain Series ordering attributes.

KEY FEATURES

  • Fixed-installation balanced pair geometry
  • Overall aluminium/polyester foil screen with drain wire
  • 18, 20 and 22 AWG Series options
  • PVC, LSZH and PE Outdoor jacket options
  • 305 m standard bulk-cable package

TYPICAL APPLICATIONS

  • Installed microphone wall plates and floor boxes
  • Conference, education and hospitality AV
  • Theatre, venue and house-of-worship infrastructure
  • Rack rooms, patch bays and audio interfaces
  • Protected outdoor microphone circuits where approved

Technical Specification

AWG / NOMINAL AREA / SERIES AVAILABILITY

Additional information
AWG18 awg, 20 awg, 22 awg
Jacket TypePVC, LSZH, PE Outdoor
Length305 m
ColourBlack
BrandTMT Global
