4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable

KEY FEATURES

  • Four-core star-quad balanced geometry
  • Foil, drain wire and overall copper braid
  • 20, 22 and 24 AWG Series options
  • PVC, LSZH and PUR / TPU jacket options
  • Exact searchable ordering code per AWG and jacket
Chat with Sales

Supplied in the UAE by AMSS from our Sharjah office (Industrial Area 18) and Dubai office (Naif, Deira), for projects across the Emirates. Request a quote

0 People watching this product now!
Description

Choosing the 4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable

Microphone cable carries low-level balanced audio, so screening and flexibility matter most. Choose the pair count for the channels on the run and the jacket for fixed or stage use. Jacket options: PVC for general indoor routes, LSZH where low smoke and zero halogen are specified for occupied buildings.

  • Type: Professional star-quad microphone and balanced analogue audio cable
  • Cores / pairs: Star quad / 4 core
  • Conductor size: 20 AWG / 22 AWG / 24 AWG
  • Conductor: Stranded copper
  • Screen: Foil screen + drain wire + copper braid
  • Package: 305 m

Related options in this range: 4 Core Star-Quad Copper-Braid Shielded Microphone Cable · 2 Core Miniature Copper-Braid Shielded Microphone Cable · 2 Core Foil-Shielded Installation Microphone Cable · 2 Core Foil + Braid Double-Shielded Flexible Microphone Cable

Order code: 04B-MQ. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable Series

TMT Global 4 Core Star-Quad Foil + Braid Double-Shielded Microphone Cable combines controlled star-quad conductor geometry with foil, drain wire and overall copper braid. This family is positioned for difficult electromagnetic environments and professional applications that require both flexible handling and enhanced screen architecture.

KEY FEATURES

  • Four-core star-quad balanced geometry
  • Foil, drain wire and overall copper braid
  • 20, 22 and 24 AWG Series options
  • PVC, LSZH and PUR / TPU jacket options
  • Exact searchable ordering code per AWG and jacket

TYPICAL APPLICATIONS

  • Broadcast studios and production facilities
  • High-EMI stages, dimmer rooms and technical areas
  • Long-run balanced microphone infrastructure
  • Touring audio and premium XLR assemblies
  • Critical low-level analogue signal paths

Technical Specification

AWG / NOMINAL AREA / SERIES AVAILABILITY

Additional information
AWG20 awg, 22 awg, 24 awg
ColourBlack
Jacket TypePUR / TPU, PVC, LSZH
BrandTMT Global
